High Strength Bonded Seal NBR Bonded Seal

High Strength Bonded Seal NBR Bonded Seal

Price: 0.01 USD Payment Terms: T/T,L/C,D/A,D/P,WU,Paypal,Money Gram Place of Origin: Zhejiang, China (Mainland)

Chat Now

    Product Detail

    Model No:     ZG Bonded seal                              Production Capacity:   10000000/month

    Delivery Date:    1-7 days                                      Style:   Mechanical Seal

    Brand Name:   ZG                                                  Means of Transport:   Ocean,Land,Air

    Packing:    1-10000/bag                                        Standard or Nonstandard:   Standard

    Material:    Rubber                                                 HS CODE:    4016931000


    The Bonded Seal comprises a metal washer and an elastomeric ring bonded inside the diameter.


    Bonded Seal Basic Info.


    Over 500 size mold for choose

    High seal performance, Oil proof, Alkali resistance

    Good abrasion resistance,

    Customized size is welcome, aging resistance, With good elastic and long lifespan


    Suitable for hydraulic pneumatic parts, and machinery equipment in rotary or stationery state

    Description:

    1. Product: Bonded Seal

    2. Material: NBR , Viton and more

    3. Color: Black, or any

    4. Parameters:

    Temperature: -60° C-+220° C

    Speed slower than: ≤ 15m/s

    5. Certification: FDA, RoHS, WRAS, DVGW

    6. Standard: ISO/AS/DIN/JIS, custom made.

    7. Quality control: ISO9001: 2000. TS16949 approved

    8. Service: OEM&ODM, design service

    9. Products Scope: Seal rings/standard&non standard rubber items

    10. Application: Transportation equipment, auto industry, electronics, engineering machine, industrial devices, household appliance

    11. Big stock, mini MOQ acceptable.

    12. Strict material traceability in ERP and barcode system.


    If you want more detailed information of this product or related problems, please contact with us, we will reply as soon as possible (general in 24 hours).



    Preferred Series - metric dimensions
    Metric Thread
    Inside DiameterOutside DiameterMetal thicknessSpot face diameterClearance hole diameterPart Number


    IDADtd3 H13d4
    M2.5
    3,106,401,006,702,70BSM000031
    M2.5
    3,106,401,306,702,70BSM100031
    M3
    3,607,501,007,633,20BS400-301
    M3
    4,107,001,007,303,20BSM000041
    M3 (M3.5)
    4,107,201,007,50 (7,35)3,20 (3,70)BS400-201
    M4
    4,507,001,007,35 (7,15)4,20BS400-202
    M4
    4,609,001,009,30 (9,13)4,30 (4,20)BS400-302
    M4
    4,908,601,008,904,30BSM000049
    M5
    5,6010,001,0010,135,20BS400-303
    M5
    5,709,001,009,30 (9,15)5,30 (5,20)BS400-203
    M5
    5,709,201,009,505,30BSM100057
    M5
    5,7010,001,0010,30 (10,15)5,30 (5,20)BS400-204
    M5 (M5.5)
    6,209,201,009,50 (9,35)5,30 (5,70)BS400-205
    M6
    6,6011,001,0011,136,20BS400-304
    M6
    6,7010,001,0010,30 (10,15)6,40 (6,20)BS400-206
    M6
    6,7011,001,0011,30 (11,15)6,40 (6,20)BS400-207
    M6
    6,7011,002,5011,35 (11,15)6,40 (6,20)BS400-208
    M6
    6,8513,271,3013,406,20BS400-305
    M6
    6,9013,201,3013,506,40BSM000069
    M6
    7,0011,401,0011,536,20BS400-306
    M6
    7,0013,401,3013,706,40BSM000070
    M6 (M6.5)
    7,1012,001,0012,30 (12,15)6,40 (6,70)BS400-209
    M6 (M6.7)
    7,3010,201,0010,50 (10,35)6,40 (6,90)BS400-210
    M6 (M8)
    8,5013,401,0013,70 (13,55)6,40 (8,20)BS400-211
    M8
    8,6013,001,0013,138,20BS400-307
    M8
    8,7013,001,0013,30 (13,15)8,40 (8,20)BS400-212
    M8
    8,7014,001,0014,30 (14,15)8,40 (8,20)BS400-213
    M8
    8,7014,201,3014,508,40BSM200087
    M8
    8,7016,001,0016,30 (16,15)8,40 (8,20)BS400-214
    M8 (M8.5)
    9,3013,301,0013,60 (13,45)8,40 (8,70)BS400-215
    M10
    10,3516,002,0016,179,95BS400-216
    M8 (M10)
    10,7016,001,5016,30 (16,15)8,40 (10,20)BS400-217
    M10
    10,7017,001,5017,1310,20BS400-310
    M8 (M10)
    10,7018,001,5018,30 (18,15)8,40 (10,20)BS400-218
    M10 (M11)
    11,4016,301,5016,60 (16,45)10,50 (11,20)BS400-219
    M11
    11,8018,101,5018,2311,20BS400-312
    M10 (M11)
    11,8018,501,5018,80 (18,65)10,50 (11,20)BS400-220
    M10 (M11)
    11,8019,101,5019,40 (19,25)10,50 (11,20)BS400-221
    M10 (M12)
    12,7018,001,5018,30 (18,15)10,50 (12,20)BS400-222
    M12
    12,7019,001,5019,1312,20BS400-313
    M10 (M12)
    12,7020,001,5020,30 (20,15)10,50 (12,20)BS400-223
    M12 (M13)
    13,7020,001,5020,30 (20,15)13,00 (13,20)BS400-224
    M12
    13,7020,602,1020,9013,00BSM100137
    M12 (M13)
    13,7022,001,5022,30 (22,15)13,00 (13,20)BS400-225
    M12
    13,7022,201,5922,5013,00BSM300137
    M13
    13,8020,101,5020,2313,20BS400-315
    M12 (M13.5)
    14,0018,701,5019,00 (18,85)13,00 ( 13,70)BS400-226
    M14
    14,7021,001,5021,1314,20BS400-316
    M12 (M14)
    14,7022,001,5022,30 (22,15)13,00 (14,20)BS400-227
    M12
    14,9022,302,1022,6013,00BSM000149
    M14 (M15)
    16,0022,701,5023,00 (22,85)15,00 (15,20)BS400-228
    M14
    16,5025,502,1025,8015,00BSM000165
    M16
    16,7023,001,5023,1316,20BS400-317
    M14 (M16)
    16,7024,001,5024,30 (24,15)15,00 (16,20)BS400-229
    M16.5
    17,2023,902,1024,0316,70BS400-319
    M17
    17,4023,701,5023,8317,20BS400-318
    M14 (M17)
    17,4024,001,5024,30 (24,15)15,00 (17,20)BS400-230
    M14
    17,4024,002,0024,3015,00BSM100174
    M16 (M17.5)
    18,0024,701,5025,00 (24,85)17,00 (17,70)BS400-231
    M16
    18,2025,402,5025,7017,00BSM000182
    M16 (M18)
    18,7026,001,5026,30 (26,15)17,00 (18,20)BS400-232
    M18
    18,7027,002,0027,1318,20BS400-320
    M18 (M20)
    20,7028,001,5028,30 (28,15)19,00 (20,20)BS400-233
    M20
    20,7029,002,0029,1320,20BS400-321
    M18 (M21)
    21,5028,702,5029,00 (28,85)19,00 (21,20)BS400-234
    M21
    21,7030,002,0030,1321,20BS400-323
    M20 (M22)
    22,5028,001,5028,30 (28,15)21,00 (22,20)BS400-235
    M20 (M22)
    22,7030,002,0030,30 (30,15)21,00 (22,20)BS400-236
    M20 (M22)
    22,7030,003,0030,30 (30,15)21,00 (22,20)BS400-237
    M20 (M22)
    22,7031,002,0031,1322,20BS400-324
    M23
    23,7032,002,0032,1323,20BS400-325
    M20 (M24)
    24,7032,002,0032,30 (32,15)21,00 (24,20)BS400-238
    M24
    24,7033,002,0033,1324,20BS400-326
    M22
    26,7035,002,0035,3023,00BSM000267
    M24
    27,0035,002,5035,3025,00BSM000270
    M26
    27,0035,302,0035,4326,20BS400-327
    M24 (M27)
    27,2036,002,0036,30 (36,15)25,00 (27,20)BS400-240
    M27
    27,7036,002,0036,1327,20BS400-328
    M28
    28,6036,002,0036,1328,20BS400-329
    M24
    28,7037,002,0037,3025,00BSM000287
    M28.5
    29,2037,502,0037,6328,70BS400-330
    M30
    30,7039,002,0039,1330,20BS400-331
    M27 (M30)
    31,0039,002,0039,30 (39,15)28,00 (30,20)BS400-242
    M27 (M33)
    33,7042,002,0042,30 (42,15; 42,13)28,00 (33,20)BS400-332**
    M27 (M33)
    33,7042,002,0042,30 (42,15; 42,13)28,00 (33,20)BS400-243**
    M27
    33,9042,803,2543,1028,00BSM000339
    M27
    33,9042,903,4043,2028,00BSM100339
    M30 (M33)
    34,3043,002,0043,30 (43,15)31,00 (33,20)BS400-244
    M30 (M36)
    36,7046,002,0046,30 (46,15)31,00 (36,20)BS400-245
    M36
    37,0048,002,5048,1336,20BS400-333
    M36 (M39)
    40,0051,002,5051,30 (51,15)37,00 (39,20)BS400-246
    M39
    40,0051,002,5051,1339,20BS400-334
    M36 (M42)
    42,7053,003,0053,30 (53,15)37,00 (42,20)BS400-247
    M42
    43,0054,002,5054,1342,20BS400-335
    M45
    46,0057,002,5057,1345,20BS400-336
    M36 (M48)
    48,7059,003,0059,30 (59,15)37,00 (48,20)BS400-248
    M48
    49,0060,002,5060,1348,20BS400-337
    M42
    51,7063,503,2563,8043,00BSM000517
    M42 (M51)
    52,0060,003,0060,30 (60,15)43,00 (51,20)BS400-249
    M48 (M52)
    53,3064,503,0064,80 (64,65)50,00 (52,20)BS400-250
    M48 (M60)
    60,7073,003,0073,30 (73,15)50,00 (60,20)BS400-251
    M68
    68,6079,503,5079,6568,20BS400-252
    M75
    76,1090,303,3890,4575,20BS400-253
    M64
    76,1090,303,4090,6066,00BSM000761
    M88
    89,09101,483,25101,6388,20BS400-254
    M125
    127,00143,675,00143,82125,20BS400-255







    ** same size




    for BA/BS../UN.. Inch thread sizeBSP threadInside DiameterOutside DiameterMetal thick-nessSpot face diameterClearance hole diameterPart Number


    IDADtd3 H13d4
    6BA
    3,056,351,226,482,79BS400-001
    1/8
    3,708,051,048,303,50BSW200005
    9/64
    4,008,381,048,703,90BSW200006
    4BA
    4,127,261,227,393,60BS400-002
    5/32
    4,709,291,049,604,50BSW200008
    2BA
    5,218,381,228,514,69BS400-003
    3/16
    5,6010,791,3711,105,40BSW200190
    7/32
    6,2011,551,3711,906,00BSW200216
    1/4
    6,8613,211,2213,346,34BS400-004
    1/4
    6,9913,341,2213,476,35BS400-005
    1/4
    7,1013,181,3713,507,00BSW200250
    5/16
    8,3113,341,2213,477,93BS400-006
    5/16
    8,6414,221,2214,357,94BS400-007
    5/16
    8,7015,161,3715,508,50BSW200312
    3/8
    10,3017,521,3717,8010,20BSW200375
    3/81/810,3715,882,0016,019,53BS400-020
    40
    11,2618,362,0018,4910,16BS400-008
    7/16
    11,6919,052,0019,1811,11BS400-009
    7/16
    11,9019,531,9019,8011,70BSW200437
    1/2
    13,7022,301,9022,5013,50BSW200500
    1/21/413,7420,572,0020,7012,70BS400-021
    9/16
    14,8622,232,0022,3614,28BS400-010
    9/16
    15,3024,681,9025,0015,00BSW200562
    60
    15,8322,232,0022,3615,23BS400-022
    5/8
    16,5225,402,0025,5315,88BS400-011
    5/8
    16,9027,051,9027,3016,80BSW200625

    3/817,2823,802,0023,9316,64BS400-023
    11/16
    18,1625,402,3425,5317,46BS400-012
    11/16
    18,5029,432,2829,7018,20BSW200687
    3/4
    19,6926,922,3427,0519,05BS400-024
    3/4
    20,3032,232,2832,5020,00BSW200750
    13/161/221,5428,582,3428,7120,64BS400-025
    13/16
    21,9034,592,2834,9021,50BSW200812
    7/85/823,4931,752,3431,8822,23BS400-026
    7/8
    23,5036,982,2837,3023,20BSW200875
    15/16
    24,2633,272,3433,4023,80BS400-013
    15/16
    25,1038,962,2839,3024,80BSW200937
    1
    26,7042,132,2842,4026,50BSW201000
    13/427,0534,932,3435,0625,41BS400-027
    1 1/16
    27,8238,612,3438,7427,00BS400-028
    1 1/8
    29,3336,582,3436,7128,57BS400-014
    1 1/8
    29,8046,912,2847,3029,50BSW201125
    1 3/167/830,8138,102,3438,2330,15BS400-029
    1 1/4
    32,6441,403,2541,5331,74BS400-015
    1 1/4
    33,0051,283,4051,4032,80BSW201250
    15/16133,8942,802,3442,9333,33BS400-030
    15/16133,8942,803,2542,9333,33BS400-031
    1 3/8
    35,9444,453,2544,5834,92BS400-016
    1 1/2
    38,9647,753,2547,8838,10BS400-017
    1 1/2
    39,5058,933,4058,3039,00BSW201500
    1 5/81 1/442,9352,383,2552,5141,29BS400-032
    1 3/4
    45,3457,153,2557,2844,44BS400-018
    1 7/81 1/248,4458,603,2558,7347,64BS400-033
    2
    51,6963,503,2563,6350,79BS400-019
    2 1/81 3/454,8969,853,2569,9853,99BS400-034
    2 1/4
    58,0470,363,2570,4957,14BS400-035

    260,5873,033,2573,1659,62BS400-036
    2 1/2
    64,3977,723,2577,8563,49BS400-037

    2 1/466,6879,503,2579,6365,50BS400-038

    2 1/276,0890,173,2590,3075,18BS400-039









    for BSP thread size
    Inside DiameterOutside DiameterMetal thick-nessSpot face diameter
    Part Number


    ID +0,2AD -0,2t ±0,15d3 +0,4

    1/16
    8,3012,701,2513
    BS400-519
    1/8
    10,4014,701,2515
    BS400-510
    1/4
    13,8518,701,2519
    BS400-511
    3/8
    17,3522,701,2523
    BS400-512
    1/2
    21,6526,701,2527
    BS400-513
    3/4
    27,3032,501,2533
    BS400-514
    1
    34,2039,502,0040
    BS400-515
    1 1/4
    42,8049,502,0050
    BS400-516
    1 1/2
    48,7055,502,0056
    BS400-517
    2
    60,5068,502,0069
    BS400-518




    BONDED SEALS SELF CENTERING
    GM 500 Dimensional series: metric series, self centering
    for Metric Thread size
    Inside DiameterOutside DiameterMetal thick-nessMetal washer IDID between self centering sealPart Number


    IDADtd3dN
    M4
    4,507,001,005,403,30BS500-8045
    M5
    5,7010,001,007,404,45BS500-8057
    M6
    6,7010,001,008,005,60BS500-8067
    M8
    8,7014,001,0010,406,40BS500-866
    M10
    10,7016,001,5012,408,05BS500-708
    M12
    12,7019,001,5014,109,73BS500-867
    M14
    14,7022,001,5016,4011,38BS500-868
    M16
    16,7024,001,5018,4013,41BS500-870
    M18
    18,7026,001,5020,4014,76BS500-872
    M20
    20,7028,001,5022,5016,76BS500-873
    M22
    22,7030,002,0024,4018,74BS500-874
    M24
    24,7032,002,0026,4020,11BS500-875



    Dimensional series: BSP, self centering
    for BSP thread size
    Inside DiameterOutside DiameterMetal thick-nessMetal washer IDID between self centeringsealPart Number


    IDADtd3dN
    BSP 1/8
    10,3715,882,0011,848,26BS800-020
    BSP 1/4
    13,7420,572,0015,2111,18BS800-021
    BSP 3/8
    17,2823,802,0018,7514,76BS800-023
    BSP 11/16
    18,1625,402,4019,6914,50BS800-071
    BSP 1/2
    21,5428,582,4723,0118,24BS800-025
    BSP 5/8
    23,4931,752,4724,9720,27BS800-026
    BSP 3/4
    27,0534,932,4728,5323,83BS800-027
    BSP 7/8
    30,8138,102,4732,2927,51BS800-029
    BSP 1
    33,8942,803,4036,8829,92BS800-030
    BSP 1 1/4
    42,9352,383,4045,9338,45BS800-032
    BSP 1 1/2
    48,4458,603,4051,3944,45BS800-033
    BSP 1 3/4
    54,8969,853,4058,3050,42BS800-034
    BSP 2
    60,5873,033,4063,6356,26BS800-036
    BSP 2 1/4
    66,6879,503,4069,9862,36BS800-038
    BSP 2 1/2
    76,0890,173,4079,3871,50BS800-039



    Welcome to buy the high strength bonded seal nbr bonded seal from us. We are one of the leading and professional China manufacturers and suppliers in this field. And our factory has bulk products in stock at your choice. Please be free to place an order. The customized order is also accepted.
Hot Tags: high strength bonded seal nbr bonded seal, China, factory, suppliers, manufacturers, customized, bulk, in stock
Related Products
Inquiry
